Features:
1. xd-symbol Exd I Mb, ExdIIAT4 Gb,ExdIIBT4 Gb
2.Category I: surface highest temperature no higher than.150C ( When coal dust may cover the motors face),
no higher than 450C ( When coal dust will not cover the surface or some protection work has been done to prevent the coal
dust accumulation)
3.Category II: surface highest temperature no higher than T1(450C), T2(300C), T3(200C), T4(150C); Terminal box with three or six terminals for rubber jacket cable (plastic cable) and steel cable.
4. Ideal for the coal mine (Exd I) and dangerous plant (Exd II AT4/ dII BT4) where methane and coal dust may be present; and the environment where there is Category II Class A and B flammable gas or the flammable mixture of air and steam in Temperature Group T1~T4.
5.PTC, PT100 and other thermal elements can be chosen to protect winding and bearings.
6.Heater can be chosen to prevent moisture.
7.VPI process applied for best electrical performance.
8.High lock rotor torque.
9.Bidirectional fan.
10.Junction box equipped with glands.
Applications:
Designed to meet international standards as replacement motors for overseas applications and machinery such as pumps, conveyors, fans, crushers, compressors, mixers and more.
Ambient temperature:-15C~35C in coal mine and -15C~40C in plant.
Altitude: not exceeding 1000m (If it exceeds this range, please consult)
Duty: S1 (Continuous)
